Victron MultiPlusII 48/5000/70-50 Inverter-Charger

$2,975.00

The Victron MultiPlus-II 48/5000/70-50 Inverter-Charger is a 48V battery inverter-charger, 70A battery charging, 5KVA (4KW) output: grid ready.

SKU: B0483 Category:

Description

Victron MultiPlus-II 48/5000/70-50 Inverter-Charger

The Victron MultiPlus-II 48/5000/70-50 Inverter-Charger is a grid-ready, 5KVA (4KW) output, battery inverter-charger.   Approved for the Australian power grid, designed to be coupled with another solar inverter, in a home AC power circuit (AC-coupled). Victron Energy has designed the MultiPlus II as a lean and efficient next generation battery inverter/charger, with many of the features of their popular Muliplus, including Power Assist, and the ability to supply power to a residence, even when the grid goes down. Can also be used off-grid, or paralleled for higher output.  Can be used with lithium, AGM and various other battery types.

Overview of Specification

  • Victron MultiPlus-II 48/5000/70-50 Inverter-Charger
  • Voltage: 48V Dc
  • Power: 5KVA
  • 4000W Max Output (3KVA)
  • 70A Max Battery charging
  • 50A Max input current & Switch-throughput current
  • Anti-Islanding for use on Australian Power Grid

Features

  • IP Rating: IP22
  • Efficiency: 96%
  • Warranty: 5 Years
  • 29kg
  • 560x320x141mm
  • AS4777.2 approval (CEC Approved PCE)
  • VE Bus, General purpose inputs/relays
  • Optional current Transformer – Grid Sensor

Brochure/Manufacturer’s Website

Quick Installation Guide

No DIY Electrical Work

Additional information

Weight 31 kg
Dimensions 56 × 32 × 14.1 cm
Brand

MPN (Part #)

Price
